    TP-Link TL-SM311LM MiniGBIC Module - 4888138

    TP-Link TL-SM311LM MiniGBIC Module - 4888138

    $41.99 CAD
    $41.99 CAD
    Sale Sold out
    Shipping calculated at checkout.

    TP-Link TL-SM311LM MiniGBIC Module

  • Manufacturer Part No. : 4888138
  • UPC : 845973030209
  • For Data Networking, Optical Network - 1 x LC/UPC 1000Base-SX Network - Optical Fiber - 62.5/125 µm, 50/125 µm - 850 nm Wavelength - Multi-mode - 1.25 Gigabit Ethernet - 1000Base-SX - 1.25 Gbit/s - 0.22 km (0.14 Mile) Maximum Distance - 1 Each
    • General Information
  • Manufacturer: TP-LINK Technologies Co., Ltd
  • Manufacturer Part Number: 4888138
  • Manufacturer Website Address: http://www.tp-link.com
  • Brand Name: TP-Link
  • Product Model: TL-SM311LM
  • Product Name: TL-SM311LM MiniGBIC Module
  • Marketing Information:

    Wave length: 850nm. Data rate: 1.25Gbps. Port type: LC/UPC. Cable length: 550m (1,800 feet) using 50/125um multi-mode fiber, 220m(720 feet) using 62.5/125um multi-mode fiber. Compatible with all SFP ports on TP-Link product including JetStream switches, and media converter MC220L. Work with MC200CM with multi-mode fiber connection. Limited lifetime warranty.

  • Packaged Quantity: 1 Each
  • Product Type: SFP (mini-GBIC)
    • Technical Information
  • Application/Usage:
    • Data Networking
    • Optical Network
    • Interfaces/Ports
  • Total Number of Ports: 1
  • Connector Type: LC/UPC
  • Interfaces/Ports Details: 1 x LC/UPC 1000Base-SX Network
    • Media & Performance
  • Media Type Supported: Optical Fiber
  • Fiber Optic Cable Core/Cladding Specification:
    • 62.5/125 µm
    • 50/125 µm
  • Fiber Optic Cable Wavelength: 850 nm
  • Fiber Mode Supported: Multi-mode
  • Ethernet Technology: 1.25 Gigabit Ethernet
  • Network Technology: 1000Base-SX
  • Maximum Distance Supported: 0.22 km (0.14 Mile)
  • Maximum Data Transfer Rate: 1.25 Gbit/s
    • Environmental Conditions
  • Minimum Operating Temperature: 32°F (0°C)
  • Maximum Operating Temperature: 158°F (70°C)
    • Physical Characteristics
  • Height: 0.20" (5.08 mm)
  • Width: 0.20" (5.08 mm)
  • Length: 0.20" (5.08 mm)
  • Weight (Approximate): 0.16 oz (4.54 g)
    • Miscellaneous
  • Package Contents:
    • TL-SM311LM MiniGBIC Module
    • Installation Guide
  • Compatibility:
    • TP-Link MC220L Gigabit Ethernet Media Converter

    TP-Link Switches:

    • T3700 series
    • T2700 series
    • T2600 series
    • T2500 series
    • T1700 series
    • T1600 series
    • T1500 series
    • 2/3/5 series
  • Country of Origin: China
  • Environmental Compliance:
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
    • Warranty
  • Limited Warranty: Lifetime

    • Materials

    Dimensions
